← Comparison Tool

💻 ThinkPad P16v Gen 3 vs Dell Pro Max 16

ThinkPad P16v Gen 3 vs Dell Pro Max 16 compared across 23 matched specifications — scores, the full spec table and a verdict.

Lenovo ThinkPad P16v Gen 3 (21RS) mobile workstation in black — side profile showing Thunderbolt 4, HDMI 2.1 and USB-A ports
ThinkPad P16v Gen 3
Lenovo
6.6
Overall Score
Best for professionals needing more memory headroom in an ISV-certified workstation.
View Full Details
Dell Pro Max 16 (MC16250) 16-inch mobile workstation, three-quarter view
Dell Pro Max 16
Dell
8.8
Overall Score
Best for workstation users wanting slightly more battery capacity and a choice of Windows 11 or Ubuntu Linux.
View Full Details
Know which one you want? Get UK pricing.
Fleet or single unit — we quote like-for-like, same working day. No obligation.
Get a quote →

ThinkPad P16v Gen 3 vs Dell Pro Max 16: performance overview

Scores based on quantifiable specification values (1-10 scale)

PerformanceDisplayBattery & ThermalsManageability & SecurityExpandability & RepairEcosystem & SoftwareValue
ThinkPad P16v Gen 3
Dell Pro Max 16
Performance
ThinkPad P16v Gen 3
7.0
Dell Pro Max 16
9.0
Display
ThinkPad P16v Gen 3
7.0
Dell Pro Max 16
9.0
Battery & Thermals
ThinkPad P16v Gen 3
7.0
Dell Pro Max 16
9.0
Manageability & Security
ThinkPad P16v Gen 3
6.0
Dell Pro Max 16
9.0
Expandability & Repair
ThinkPad P16v Gen 3
6.0
Dell Pro Max 16
9.0
Ecosystem & Software
ThinkPad P16v Gen 3
7.0
Dell Pro Max 16
8.0
Value
ThinkPad P16v Gen 3
6.3
Dell Pro Max 16
8.8

Detailed Specifications

Specification
ThinkPad P16v Gen 3
Lenovo
Dell Pro Max 16
Dell
Performance
ProcessorIntel Core Ultra 7 255H (Series 2 H) — 16 cores / 16 threads, up to 5.1 GHz, 24 MB cache, non-vProIntel Core Ultra 5 235H / 7 255H / 7 265H / 9 285H (45 W, up to 16 cores)
CPU cores16 cores (6P + 8E + 2LP) / 16 threadsUp to 16 cores (Core Ultra 7 255H / 265H, Ultra 9 285H)
GraphicsNVIDIA RTX PRO 2000 Blackwell 8 GB GDDR7 (21RS004KUK) or RTX PRO 1000 Blackwell 8 GB GDDR7 (21RS004JUK) discrete + Intel Arc 140T integratedIntel Graphics (integrated) or NVIDIA RTX PRO 500 (6 GB) / RTX PRO 1000 (8 GB) / RTX PRO 2000 (8 GB) Blackwell, GDDR7
Discrete GPUDiscrete NVIDIA RTX PRO 2000 / 1000 Blackwell (8 GB GDDR7)NVIDIA RTX PRO 500 / 1000 / 2000 Blackwell discrete option, up to 8 GB GDDR7
Memory & storage
Maximum memory✓32 GB DDR5-5600 (2× 16 GB SO-DIMM); two slots, to 96 GB DDR5-6400 CSODIMM, non-ECCUp to 64 GB DDR5-6400 (2 × 32 GB CSODIMM), 2 slots
Memory typeDDR5-5600 SO-DIMM (2 slots), non-ECC; to DDR5-6400 CSODIMMDDR5 SODIMM (5600 MT/s) or CSODIMM (6400 MT/s), 2 slots
Maximum storage1 TB M.2 2280 PCIe Gen5 NVMe SSD (Opal 2.0); 2nd M.2 2280 slot free, RAID 0/1, to 4 TB (2 TB per drive)2× M.2 PCIe Gen4 NVMe slots (drives up to 2 TB each, up to 4 TB total; self-encrypting options)
Display
Display size16.0″16.0"
Resolution1920×1200 (WUXGA); 4K OLED option1920 × 1200 or 2560 × 1600
Brightness✓400 nits (stocked); 500-nit sRGB and 4K OLED to orderUp to 400 nits (WVA)
PanelWUXGA IPS anti-glare, 45% NTSC, TÜV Low Blue Light; 500-nit sRGB and 4K OLED options16.0" FHD+ (1920 × 1200) 60 Hz WVA (touch option) or QHD+ (2560 × 1600) 120 Hz WVA 100% sRGB, anti-glare, 300 nits (400-nit FHD+ option), 16:10
Touchscreen--FHD+ touch panel option
Connectivity
Thunderbolt / USB4 ports2× Thunderbolt 4 (USB-C, PD 3.1 140 W in / 15 W out)2× Thunderbolt 4 (40 Gbps, PD, DisplayPort)
Ports2× Thunderbolt 4 (USB-C, PD 3.1 140 W in / 15 W out), HDMI 2.1 (8K/60), 2× USB-A 5 Gbps, GbE RJ-45, SD Express 7.0, 3.5 mm combo, Kensington Nano2× Thunderbolt 4 (40 Gbps, PD, DisplayPort), 2× USB 3.2 Gen 1 (one PowerShare), HDMI 2.1, RJ-45 1 GbE, microSD, headset jack; smart-card reader optional
Mobile broadband (4G/5G) option5G Sub-6 (Rolling Wireless RW350R-GL, eSIM) — antenna-ready, not fitted on stocked builds5G MediaTek T700 (DW5933e), eSIM capable (option)
Physical
Weight (from)~2.1 kg (4.6 lb); aluminium top, PC-ABS base, blackFrom 2.10 kg (4.65 lb)
Dimensions361.5 × 248.6 × 19.55 mm (26.3 mm max)358 × 256 × 15.08–19.08 mm (25.60 mm peak)
Security & management
Intel vProvPro available in the family on Core Ultra 7 265H / Ultra 9 285H; stocked 255H builds non-vProvPro on Core Ultra 5 235H, Ultra 7 265H and Ultra 9 285H (Ultra 7 255H is non-vPro)
Copilot+ PC (40+ TOPS NPU)AI-ready workstation — Intel AI Boost NPU up to 13 TOPS, below the 40-TOPS Copilot+ bar--
Battery
Battery capacity90 Wh Li-ion, Rapid Charge (80% in 1 hr)✓4-cell 64 Wh or 6-cell 96 Wh (ExpressCharge capable)
Rated battery life--ExpressCharge capable; Dell lists no rated runtime
Support
Operating systemWindows 11 Pro · MIL-STD-810H tested · ISV-certified · EPEAT Gold / ENERGY STAR 9.0 / TCO gen 10Windows 11 Pro or Home, Ubuntu Linux 22.04 LTS
Base warrantyLenovo base warranty; Premier Support uplifts quoted per configuration1- to 5-year hardware warranty or ProSupport options; Accidental Damage Protection available
Performance
Processor
ThinkPad P16v Gen 3Intel Core Ultra 7 255H (Series 2 H) — 16 cores / 16 threads, up to 5.1 GHz, 24 MB cache, non-vPro
Dell Pro Max 16Intel Core Ultra 5 235H / 7 255H / 7 265H / 9 285H (45 W, up to 16 cores)
CPU cores
ThinkPad P16v Gen 316 cores (6P + 8E + 2LP) / 16 threads
Dell Pro Max 16Up to 16 cores (Core Ultra 7 255H / 265H, Ultra 9 285H)
Graphics
ThinkPad P16v Gen 3NVIDIA RTX PRO 2000 Blackwell 8 GB GDDR7 (21RS004KUK) or RTX PRO 1000 Blackwell 8 GB GDDR7 (21RS004JUK) discrete + Intel Arc 140T integrated
Dell Pro Max 16Intel Graphics (integrated) or NVIDIA RTX PRO 500 (6 GB) / RTX PRO 1000 (8 GB) / RTX PRO 2000 (8 GB) Blackwell, GDDR7
Discrete GPU
ThinkPad P16v Gen 3Discrete NVIDIA RTX PRO 2000 / 1000 Blackwell (8 GB GDDR7)
Dell Pro Max 16NVIDIA RTX PRO 500 / 1000 / 2000 Blackwell discrete option, up to 8 GB GDDR7
Memory & storage
Maximum memory
ThinkPad P16v Gen 332 GB DDR5-5600 (2× 16 GB SO-DIMM); two slots, to 96 GB DDR5-6400 CSODIMM, non-ECC
Dell Pro Max 16Up to 64 GB DDR5-6400 (2 × 32 GB CSODIMM), 2 slots
Memory type
ThinkPad P16v Gen 3DDR5-5600 SO-DIMM (2 slots), non-ECC; to DDR5-6400 CSODIMM
Dell Pro Max 16DDR5 SODIMM (5600 MT/s) or CSODIMM (6400 MT/s), 2 slots
Maximum storage
ThinkPad P16v Gen 31 TB M.2 2280 PCIe Gen5 NVMe SSD (Opal 2.0); 2nd M.2 2280 slot free, RAID 0/1, to 4 TB (2 TB per drive)
Dell Pro Max 162× M.2 PCIe Gen4 NVMe slots (drives up to 2 TB each, up to 4 TB total; self-encrypting options)
Display
Display size
ThinkPad P16v Gen 316.0″
Dell Pro Max 1616.0"
Resolution
ThinkPad P16v Gen 31920×1200 (WUXGA); 4K OLED option
Dell Pro Max 161920 × 1200 or 2560 × 1600
Brightness
ThinkPad P16v Gen 3400 nits (stocked); 500-nit sRGB and 4K OLED to order
Dell Pro Max 16Up to 400 nits (WVA)
Panel
ThinkPad P16v Gen 3WUXGA IPS anti-glare, 45% NTSC, TÜV Low Blue Light; 500-nit sRGB and 4K OLED options
Dell Pro Max 1616.0" FHD+ (1920 × 1200) 60 Hz WVA (touch option) or QHD+ (2560 × 1600) 120 Hz WVA 100% sRGB, anti-glare, 300 nits (400-nit FHD+ option), 16:10
Touchscreen
ThinkPad P16v Gen 3--
Dell Pro Max 16FHD+ touch panel option
Connectivity
Thunderbolt / USB4 ports
ThinkPad P16v Gen 32× Thunderbolt 4 (USB-C, PD 3.1 140 W in / 15 W out)
Dell Pro Max 162× Thunderbolt 4 (40 Gbps, PD, DisplayPort)
Ports
ThinkPad P16v Gen 32× Thunderbolt 4 (USB-C, PD 3.1 140 W in / 15 W out), HDMI 2.1 (8K/60), 2× USB-A 5 Gbps, GbE RJ-45, SD Express 7.0, 3.5 mm combo, Kensington Nano
Dell Pro Max 162× Thunderbolt 4 (40 Gbps, PD, DisplayPort), 2× USB 3.2 Gen 1 (one PowerShare), HDMI 2.1, RJ-45 1 GbE, microSD, headset jack; smart-card reader optional
Mobile broadband (4G/5G) option
ThinkPad P16v Gen 35G Sub-6 (Rolling Wireless RW350R-GL, eSIM) — antenna-ready, not fitted on stocked builds
Dell Pro Max 165G MediaTek T700 (DW5933e), eSIM capable (option)
Physical
Weight (from)
ThinkPad P16v Gen 3~2.1 kg (4.6 lb); aluminium top, PC-ABS base, black
Dell Pro Max 16From 2.10 kg (4.65 lb)
Dimensions
ThinkPad P16v Gen 3361.5 × 248.6 × 19.55 mm (26.3 mm max)
Dell Pro Max 16358 × 256 × 15.08–19.08 mm (25.60 mm peak)
Security & management
Intel vPro
ThinkPad P16v Gen 3vPro available in the family on Core Ultra 7 265H / Ultra 9 285H; stocked 255H builds non-vPro
Dell Pro Max 16vPro on Core Ultra 5 235H, Ultra 7 265H and Ultra 9 285H (Ultra 7 255H is non-vPro)
Copilot+ PC (40+ TOPS NPU)
ThinkPad P16v Gen 3AI-ready workstation — Intel AI Boost NPU up to 13 TOPS, below the 40-TOPS Copilot+ bar
Dell Pro Max 16--
Battery
Battery capacity
ThinkPad P16v Gen 390 Wh Li-ion, Rapid Charge (80% in 1 hr)
Dell Pro Max 164-cell 64 Wh or 6-cell 96 Wh (ExpressCharge capable)
Rated battery life
ThinkPad P16v Gen 3--
Dell Pro Max 16ExpressCharge capable; Dell lists no rated runtime
Support
Operating system
ThinkPad P16v Gen 3Windows 11 Pro · MIL-STD-810H tested · ISV-certified · EPEAT Gold / ENERGY STAR 9.0 / TCO gen 10
Dell Pro Max 16Windows 11 Pro or Home, Ubuntu Linux 22.04 LTS
Base warranty
ThinkPad P16v Gen 3Lenovo base warranty; Premier Support uplifts quoted per configuration
Dell Pro Max 161- to 5-year hardware warranty or ProSupport options; Accidental Damage Protection available
★

Expert Analysis

Specs web-verified from manufacturer datasheets · Servnet-reviewed · Last reviewed 26 Jul 2026

The Dell Pro Max 16 and Lenovo ThinkPad P16v Gen 3 are closely matched mobile workstations, with the Dell offering a slightly larger battery and the Lenovo a higher memory ceiling. Both use Intel Core Ultra H-series processors with up to 16 cores and NVIDIA RTX PRO 1000 or 2000 Blackwell graphics with 8 GB GDDR7, and both provide two M.2 SSD slots with up to 4 TB in total. Lenovo supports up to 96 GB of memory versus Dell's 64 GB across two SO-DIMM slots, useful for data-heavy workflows. The Lenovo's stocked 400-nit panel matches the Dell's brightest 400-nit option, with a 500-nit panel available to order, while the Dell's 96 Wh battery option edges ahead of the Lenovo's 90 Wh unit. Weight is effectively level at around 2.1 kg for both. Both offer vPro on selected processors (the Dell on the 235H, 265H and 285H; the Lenovo on the 265H and 285H), and the Dell adds an Ubuntu Linux option. Overall, the Dell Pro Max 16 suits buyers wanting a little more battery capacity, while the ThinkPad P16v Gen 3 suits those needing more memory headroom with ISV certifications.

ThinkPad P16v Gen 3
Best for professionals needing more memory headroom in an ISV-certified workstation.
Dell Pro Max 16
Best for workstation users wanting slightly more battery capacity and a choice of Windows 11 or Ubuntu Linux.
