🔀 FortiSwitch FS-224E vs Cisco 9200-24T
AI-powered analysis across 26 matched specifications
Performance Overview
Scores based on quantifiable specification values (1-10 scale)
Detailed Specifications
| Specification | FortiSwitch FS-224E Fortinet | Cisco Catalyst 9200-24T Cisco |
|---|---|---|
| Key Metrics | ||
| Model / Part Number | FS-224E | C9200-24T-E |
| Access Ports | 24 × Gigabit Ethernet RJ-45 | 24 × 10/100/1000 Mbps RJ45 |
| Uplink Ports | 4 × Gigabit SFP | 4 × 1G SFP |
| Switching Capacity | 56 Gbps (non-blocking) | 128 Gbps |
| Forwarding Rate | 83 Mpps | 95.2 Mpps |
| Network Latency | < 1µs | -- |
| Networking | ||
| VLAN Support | 4,096 | -- |
| MAC Address Table | 16,000 entries | 32,000 |
| Packet Buffer | 1.5 MB | -- |
| Layer 2/3 Features | VLANs, STP/RSTP/MSTP, LACP, IGMP Snooping, QoS, Guest VLAN | -- |
| MACsec Encryption | -- | IEEE 802.1AE hardware |
| Stacking Capability | Stackable: up to 300 switches per FortiGate | Optional StackWise-160 (up to 8 switches, 160 Gbps) |
| Compute | ||
| Processor / ASIC | -- | Cisco Uadp 2.0 (programmable) |
| DRAM / Flash | 512 MB DDR3 / 128 MB | -- |
| I/O & Ports | ||
| Port Configuration | 24 × Gigabit Ethernet RJ-45, 4 × Gigabit SFP | 24 × 10/100/1000 Mbps RJ45, 4 × 1G SFP |
| Management | ||
| Management Options | Standalone · FortiLink (FortiGate) · FortiCloud | Cisco IOS-XE with YANG/NETCONF/RESTCONF · DNA Center intent-based networking |
| Power | ||
| Power Consumption | 17.2W average / 17.3W maximum | Max Power Draw: 40W (non-PoE) |
| Power Supply | -- | Internal AC (100–240V); optional redundant PSU |
| Physical / Environmental | ||
| Form Factor | 1U Rack-mount (19") | 1U rack-mount |
| Dimensions | 440 × 310 × 44 mm (17.32 × 12.20 × 1.73 in) | -- |
| Weight | 2.17 kg (4.78 lbs) | 4.5 kg |
| Cooling | Fanless (passive) | 1 × fan (front-to-back) |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) | -- |
| Security | ||
| Security Features | -- | MACsec hardware encryption |
| Software & OS Compatibility | ||
| Operating System / Software | -- | Cisco IOS-XE |
| Warranty & Support | ||
| Certifications | FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 | -- |
Expert Analysis
The FortiSwitch FS-224E and Cisco Catalyst 9200-24T represent distinct approaches to enterprise switching, each with compelling strengths for specific deployment scenarios. The FortiSwitch excels in environments where silent operation, low power consumption, and tight integration with Fortinet's security ecosystem are paramount. With its fanless design consuming just 17.2W average power and sub-1µs latency, it's particularly well-suited for edge deployments, small offices, or any location where noise reduction and energy efficiency are priorities. The ability to manage up to 300 switches through a single FortiGate provides impressive scalability for distributed networks within the Fortinet environment.
The Cisco Catalyst 9200-24T offers superior raw performance and enterprise-grade features, making it the stronger choice for core networking roles. Its 128 Gbps switching capacity and 95.2 Mpps forwarding rate significantly outperform the FortiSwitch's 56 Gbps and 83 Mpps, while the programmable Uadp 2.0 ASIC provides future-proofing through software-defined capabilities. The inclusion of hardware MACsec encryption, StackWise-160 with 160 Gbps stacking bandwidth, and Cisco's comprehensive IOS-XE management ecosystem with DNA Center integration positions this switch for demanding enterprise environments where security, programmability, and management sophistication are critical.
Value propositions differ substantially: the FortiSwitch delivers exceptional value through its silent operation and seamless security integration, while the Catalyst justifies its likely higher cost through superior performance, advanced security features, and Cisco's mature enterprise networking ecosystem. Organisations heavily invested in Fortinet's security fabric will find the FS-224E's integration compelling, while those prioritising maximum throughput, advanced programmability, and enterprise management features should lean toward the Catalyst 9200-24T.
