4th Generation — 4K KVM over IP
The Raritan Dominion KX IV-101 is the fourth-generation single-port KVM over IP switch delivering 4K resolution at 30fps, HDMI native connectivity, fanless design, and BIOS-level remote access for a single server or workstation — accessible from LAN, WAN, or the internet via any browser.
Get Pricing — Speak to Our Team
Competitive pricing · Response within 4 hours
The KX IV-101 delivers 4K resolution (3840×2160) at up to 30fps when used with the Dominion KX IV Enhanced User Station. In HD modes (1920×1080 and 1920×1200), full 60fps with 4:4:4 colour fidelity ensures crisp text and accurate colour reproduction for graphics-intensive server interfaces.
Native HDMI port covers modern servers directly. Optional adapters enable connection to VGA (legacy servers), DVI, Mini DisplayPort, and USB-C — making the KX IV-101 compatible with virtually any server or workstation video output without additional hardware at the remote end.
Access the KX IV-101 from any modern browser on Windows, Linux, or macOS without Java plugins or client software installation. BIOS-level access means pre-boot operations, firmware updates, and OS recovery are all accessible remotely exactly as if sitting at the keyboard.
Up to 8 concurrent remote users can access the same server via the KX IV-101 simultaneously — each with independent keyboard, video, and mouse control. Configurable permissions allow read-only viewing or full interactive sessions per user role.
The KX IV-101 contains no moving parts. Fanless operation eliminates the main source of hardware failure in 1U appliances and produces zero noise — ideal for office-side server rooms, sound-sensitive environments, or dense rack deployments where fan noise accumulates.
Virtual media transfer (mounting USB drives or ISO images remotely) operates at three times the speed of the previous KX III generation. Firmware updates, OS re-installations, and diagnostic tool deployment over virtual media are dramatically faster, reducing maintenance windows.
FIPS 140-2 validated AES encryption secures all KVM traffic in transit. Integration with LDAP, RADIUS, and Active Directory enables centralised authentication with existing enterprise identity infrastructure. Two-factor authentication support adds an additional layer of security for privileged access.
Add the KX IV-101 to a Raritan CommandCenter Secure Gateway deployment for centralised access management across hundreds of KVM devices, unified audit logging, and single-sign-on across all Raritan infrastructure from a single web interface.
The Raritan Dominion KX IV-101 (model DKX4-101) represents the fourth generation of Raritan's flagship single-port KVM over IP platform — the most advanced single-server remote access appliance in the Dominion range. Released with firmware 4.5.0 in September 2025, the KX IV-101 is a current, actively developed product with continuous updates from Raritan's engineering team.
At its core, the KX IV-101 delivers genuine 4K resolution (3840×2160) at 30fps when paired with the Dominion KX IV Enhanced User Station — the only single-port IP KVM in its class with verified 4K output. In standard HD modes (1920×1080 and 1920×1200), 60fps operation with 4:4:4 colour encoding provides the visual quality expected for managing modern servers, graphical workloads, and display-intensive applications.
The transition from KX III to KX IV brings meaningful performance improvements beyond resolution: virtual media transfer runs at three times the speed of the previous generation, enabling rapid firmware deployments and OS installations over the IP network without physical USB access to the server. The fanless design eliminates the primary failure mode of rack-mounted appliances, and the complete removal of Java dependencies means any modern browser provides full functionality without client software management.
Security is built into every layer. FIPS 140-2 validated AES encryption applies to all KVM traffic. LDAP, RADIUS, and Active Directory integration centralises authentication in enterprise environments. Optional DSAM (Dominion Serial Access Module) expansion adds up to 8 serial device connections to a single KX IV-101, enabling serial console access to network devices, UPS systems, and PDUs alongside server KVM in a single rack-mounted appliance.
Provide secure BIOS-level remote access to a critical server — database, domain controller, or primary application server — where out-of-band management is essential during OS failures, firmware updates, or network configuration changes.
Deploy a KX IV-101 at a co-location facility or remote site to enable full server management without dispatching an engineer. Browser-based access from any location removes the need for physical presence at remote infrastructure.
Mount ISO images or USB tools remotely via virtual media for OS re-installation, disaster recovery booting, and firmware updates — without physical access to the server room or co-location cage.
Integrate with CommandCenter and Active Directory for audited, role-based access. Every session is logged with user identity, timestamp, and recording — providing the audit trail required for PCI DSS, ISO 27001, and government compliance frameworks.
