Enterprise Data Centre Power. 500 to 1500 kVA.
The APC Galaxy VX is a high-efficiency 3-phase online UPS delivering 500 to 1500 kVA for large data centres — with up to 96.8% efficiency, modular parallel redundancy up to 6 units, flexible battery options, and full EcoStruxure IT DCIM integration.
Get Pricing — Speak to Our Team
Competitive pricing · Response within 4 hours
Galaxy VX is available in six power ratings from 500 kVA to 1500 kVA. Modular parallel architecture allows multiple units to operate as a single logical UPS — N+1 redundancy provides complete failover for the full system, or 2N provides fully isolated power paths for tier 4 data centres.
Galaxy VX achieves 96.8% efficiency in online double-conversion mode. In a 1 MW UPS installation, the difference between 94% and 96.8% efficiency is approximately 28kW of continuous power loss reduction — saving significant costs and improving data centre PUE.
The IGBT-based active rectifier delivers low Total Harmonic Distortion on the input — reducing reactive current draw on generators and building transformers. Critical for data centres with diesel generator backup where high-THD UPS loads cause generator derating.
Galaxy VX supports compact internal string arrangements through to multiple external battery cabinets. VRLA and lithium-ion battery cabinets are available. Battery configuration can be adjusted post-installation as runtime requirements evolve.
Galaxy VX integrates natively with Schneider Electric EcoStruxure IT DCIM — providing real-time power chain visibility from utility input through UPS, PDU, and server PSU. AI-driven capacity planning, fault prediction, and energy optimisation.
Integrated static bypass and optional maintenance bypass cabinet allow UPS bypass without interrupting critical load. Combined with parallel redundancy, this enables zero-downtime UPS maintenance.
The APC Galaxy VX is Schneider Electric's primary 3-phase data centre UPS platform for medium-to-large data centres requiring 500 kVA to 1500 kVA. With online double-conversion topology, IGBT-based active rectifier, and up to 96.8% efficiency, the Galaxy VX provides the highest levels of power quality and industry-leading energy efficiency simultaneously.
The parallel redundancy architecture (up to 6 units) enables N+1 redundancy without doubling infrastructure, or 2N configurations with fully isolated power paths for tier 4 requirements. Each Galaxy VX unit in a parallel system shares load equally and provides automatic failover with no manual intervention required.
EcoStruxure IT integration connects Galaxy VX to PDU, cooling, and building management data for complete power chain visibility — increasingly important for organisations with sustainability reporting requirements, where precise power consumption from the UPS layer is required for Scope 2 carbon accounting and PUE reporting.
Galaxy VX is the standard choice for enterprise data centres with 500kW–1.5MW IT load — providing N+1 or 2N parallel redundancy that meets Uptime Institute Tier III and Tier IV requirements.
Online double-conversion with zero transfer time and parallel 2N redundancy provides the availability required by financial trading floors, stock exchanges, and mission-critical government infrastructure.
NHS data centres require continuous uninterruptible power with maintenance capability. Galaxy VX parallel architecture enables maintenance without downtime for EPR and clinical systems.
96.8% efficiency and EcoStruxure IT integration enable precise PUE measurement — supporting LEED, BREEAM, and EU Energy Efficiency Directive compliance.
